20W LED 600mm Diffused Batten
SKU: 220SBDIFFNon Emergency LightsDiffused Wide Batten, Non-Emergency
A non-emergency LED diffused wide batten with a prismatic diffuser for comfortable, glare-controlled general lighting in offices and retail.
- Long-life LED rated to 50,000 hours
- 2000 lm light output
- Large terminal block for fast connection
- IP20, surface mount
- Compliant with AS/NZS 60598.1
Specifications & Downloads
Documentations & Downloads
Technical Specifications
- Operating Voltage
- 220-260V; 50Hz
- Operating Temperature
- -25° - 45° C
- IP Rating
- IP20
- Wiring
- Large Terminal Block
- Mounting Type
- Surface Mount
- Construction
- Powder Coated Metal Body and Prismatic
- Power Factor
- >0.95
- Standards
- AS/NZS 60598.1
- EMC
Ordering Information
- Carton Qty
- 4 pieces
- Weight
- 1.8kg (unit) - 7.2kg (box)
- Dimension (L X W X H)
- 620mm x 125mm x 91mm
Battery and Leds
- Power Consumption
- 20W
- Lens
- 50,000 Hours
- Lumens
- 2000lm
- Colour Temp
- 5000k
- Beam Angle
- 110 Degrees
Frequently asked questions
Is the 220SBDIFF compliant with Australian Standards?
Yes. It meets AS/NZS 60598.1, is EMC compliant.
Where can it be installed?
It is designed for surface mount installation, carries an IP20 ingress protection rating, and operates between -25° - 45° C.
How is it wired and installed?
Connection is via large terminal block. Construction is powder coated metal body and prismatic.
What are the dimensions and carton quantity?
Dimensions are 620mm x 125mm x 91mm (L x W x H), weight is 1.8kg (unit) - 7.2kg (box), supplied 4 pieces per carton.
Does it come in other finishes?
Yes — this family is also available as 440SBDIFF (Standard).
